Digital exhaust gas meter display temperature indicator

Digital exhaust gas temperature display, -50 to +1150 °C

Compact digital exhaust gas temperature display for precise monitoring of exhaust gas temperature, for example in vehicles with turbo or motorsports modifications. The display uses a K-type thermocouple and allows for measurements across a wide temperature range from -50 to +1150 °C.

Thanks to the fast measurement rate of 0.3 seconds , temperature changes can be detected quickly. The temperature is displayed in 1-°C increments .

The compact housing, with an installation size of only 45 × 22 mm is ideal for installation in dashboards, auxiliary instrument holders, or motorsports applications.

Technical Specifications:

• Measurement principle: K-type thermocouple
• Measurement range: -50 to +1150 °C
• Accuracy: ±1%
• Resolution: 1 °C
• Measurement rate: 0.3 s
• Display: 4 digits
• Digit height: 10 mm
• Housing dimensions: 48 × 24 × 65 mm (W × H × D)
• Mounting dimensions: 45 × 22 mm
• Compact design
• Suitable for monitoring exhaust gas temperatures in turbo, tuning, and motorsports applications
